Application
Low-temperature resistant cable ties are suitable for use in low-temperature environments. Low-temperature resistant additives are added to the PA66 material, it can maintain stable performance without brittle breakage under ultra-low-temperature conditions (-20℃~ -40℃).It is suitable for wire harnesses, equipment fixing, food packaging and other occasions under the low temperature environment such as freezing storage, freezing workshop and so on.
Technical features
- MATERIAL: PA66（low temperature resistant）
- Flammability of raw material：UL94V-2
- Humidity absorption：2.7%-2.8%（23℃-50%RH）
- Installation temperature: -40°C ~+85°C.
- Working temperature:-40°C ~+85°C.
- Good resistance to bases, oils, greases, oil derivates,chloride solvents. Limited resistance to acids. Not resistant to phenols.
- Color: the standard color is natural;black(Includes normal types for indoor use and UV resistant for outdoor use.)
| Type | Length | Width(mm) | Max.Bundle Dia.(mm) | Min tensile strength | ||
| Inch | mm | lbs | Kgs | |||
| WD-3×100 | 4″ | 100 | 2.5 | 22 | 18 | 8 |
| WD-3×120 | 4.7″ | 120 | 2.5 | 30 | 18 | 8 |
| WD-3×150 | 6″ | 150 | 2.5 | 35 | 18 | 8 |
| WD-3×160 | 6.3” | 160 | 2.5 | 40 | 18 | 8 |
| WD-3×200 | 8″ | 200 | 2.5 | 50 | 18 | 8 |
| WD-4×100 | 4″ | 100 | 3.6 | 22 | 40 | 18 |
| WD-4×120 | 4.7” | 120 | 3.6 | 30 | 40 | 18 |
| WD-4×150 | 6″ | 150 | 3.6 | 35 | 40 | 18 |
| WD-4×160 | 7” | 160 | 3.6 | 42 | 40 | 18 |
| WD-4×200 | 8” | 200 | 3.6 | 50 | 40 | 18 |
| WD-4×250 | 10″ | 250 | 3.6 | 65 | 40 | 18 |
| WD-4×280 | 11″ | 280 | 3.6 | 75 | 40 | 18 |
| WD-4×300 | 12″ | 300 | 3.6 | 80 | 40 | 18 |
| WD-4×350 | 13.8 | 350 | 3.6 | 90 | 40 | 18 |
| WD-4×370 | 14.62″ | 370 | 3.6 | 102 | 40 | 18 |
| WD-4×400 | 16″ | 400 | 3.6 | 110 | 40 | 18 |
| WD-5×100 | 4″ | 100 | 4.8 | 22 | 50 | 22 |
| WD-5×120 | 4.7″ | 120 | 4.8 | 24 | 50 | 22 |
| WD-5×150 | 6″ | 150 | 4.8 | 35 | 50 | 22 |
| WD-5×180 | 7″ | 180 | 4.8 | 42 | 50 | 22 |
| WD-5×200 | 8″ | 200 | 4.8 | 50 | 50 | 22 |
| WD-5×250 | 10″ | 250 | 4.8 | 65 | 50 | 22 |
| WD-5×280 | 11″ | 280 | 4.8 | 82 | 50 | 22 |
| WD-5×300 | 12″ | 300 | 4.8 | 82 | 50 | 22 |
| WD-5×350 | 14″ | 350 | 4.8 | 90 | 50 | 22 |
| WD-5×380 | 15″ | 380 | 4.8 | 102 | 50 | 22 |
| WD-5×400 | 16* | 400 | 4.8 | 105 | 50 | 22 |
| WD-5×430 | 16.9″ | 432 | 4.8 | 120 | 50 | 22 |
| WD-5×450 | 17.7″ | 450 | 4.8 | 125 | 50 | 22 |
| WD-5×500 | 19.96″ | 500 | 4.8 | 150 | 50 | 22 |
| WD-5×550 | 21.6″ | 550 | 4.8 | 175 | 50 | 22 |
| WD-8×200 | 8″ | 200 | 7.6 | 50 | 100 | 45 |
| WD-8×250 | 10″ | 250 | 7.6 | 65 | 100 | 45 |
| WD-8×300 | 12″ | 300 | 7.6 | 82 | 100 | 45 |
| WD-8×350 | 15″ | 350 | 7.6 | 90 | 100 | 45 |
| WD-8×380 | 14.6″ | 370 | 7.6 | 102 | 100 | 45 |
| WD-8×400 | 16″ | 400 | 7.6 | 105 | 100 | 45 |
| WD-8×450 | 18″ | 450 | 7.6 | 118 | 100 | 45 |
| WD-8×500 | 20″ | 500 | 7.6 | 150 | 100 | 45 |
| WD-8×550 | 21.6″ | 550 | 7.6 | 165 | 100 | 45 |
| WD-8×600 | 23.6″ | 600 | 7.6 | 180 | 100 | 45 |
| WD-8×650 | 25.6″ | 650 | 7.6 | 195 | 100 | 45 |
| WD-10×400 | 16″ | 400 | 9 | 105 | 175 | 75 |
| WD-10×450 | 18″ | 450 | 9 | 130 | 175 | 75 |
| WD-10×500 | 20″ | 500 | 9 | 150 | 175 | 75 |
| WD-10×550 | 21.6″ | 550 | 9 | 165 | 175 | 75 |
| WD-10×600 | 23.6″ | 600 | 9 | 165 | 175 | 75 |
| WD-10×650 | 25.6″ | 650 | 9 | 165 | 175 | 75 |
| WD-10×700 | 28″ | 700 | 9 | 175 | 175 | 75 |
| WD-10×720 | 28.3″ | 720 | 9 | 180 | 175 | 75 |
| WD-10×760 | 29.5″ | 760 | 9 | 220 | 175 | 75 |
| WD-10×800 | 31.5″ | 800 | 9 | 180 | 175 | 75 |
| WD-10×850 | 34.7″ | 850 | 9 | 230 | 175 | 75 |
| WD-10×900 | 35.5″ | 900 | 9 | 265 | 175 | 75 |
| WD-10×1020 | 40.2″ | 1020 | 9 | 295 | 175 | 75 |
| WD-10×1200 | 48″ | 1200 | 9 | 345 | 175 | 75 |
| WD-12×400 | 16″ | 400 | 12 | 105 | 230 | 100 |
